Product Description
The 2-gang in wall switch is an universal, Z-Wave Plus V2 compatible device that can work with various types of light sources. The device allows for controlling on/off of lights. The module may be controlled wirelessly, through the Z-Wave network primary controller, or through the switch keys connected to it. The switch can also control other Z-Wave devices using “ON” “OFF” control commands and activate scenes in Gateways. In addition, the device is equipped with power metering (voltage, current, energy and power) and over current protection.
The in wall switch can be included and operated in any Z-Wave network with other Z-Wave certified devices from other manufacturers and/or other applications. All non-battery operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network.
If the user's gateway also supports smartstart, add the device by scanning the QR code, Smartstart allows users to quickly add devices to the gateway by scanning the device's QR code. After adding the device by scanning QR code, wait for a while or reset power of the device, the device will be added to the gateway automatically. Please find the QR code on the casing of the device.
The encryption mode that the switch supports is S2 Unauthenticated. When the device is being included into a Z-Wave network, you can use your primary controller/gateway to enable encryption mode or disable encryption. (The primary controller/gateway shall support encryption mode configuration). The switch supports OTA and can update firmware wirelessly.
Key Features
• An universal, Z-Wave Plus V2 compatible device that can work with various types of light sources
• Allows for controlling on/off of lights
• Can be controlled wirelessly, through the Z-Wave network primary controller, or through the switch keys connected to it
• Can also control other Z-Wave devices using “ON” “OFF” control commands and activate scenes in Gateways
• Is equipped with power metering (voltage, current, energy and power) and over current protection
• Can be included and operated in any Z-Wave network with other Z-Wave certified devices from other manufacturers and/or other applications
• Makes all non-battery operated nodes within the network act as repeaters regardless of vendor to increase reliability of the network
• Can be added by scanning the QR code if the user's gateway also supports smartstart
• Allows users to quickly add devices to the gateway by scanning the device's QR code
• Supported encryption mode: S2 Unauthenticated
• Supports OTA and can update firmware wirelessly
