Ultra-Thin DALI LED Controller for Magnet Track Light SRP-2309-MT-48VCCT100-500S

This ultra-slim DALI DT8 LED controller is specially designed for magnetic track lighting and linear lighting systems, providing a compact solution for space-constrained installations. With a 48V DC input and two-channel constant current output adjustable from 100mA to 500mA via DIP switches, it supports a maximum output power of 20W. The built-in DALI-2 interface supports DT8 color control, while deep, smooth, flicker-free dimming down to 0.1% enables precise lighting adjustment. Designed for magnetic absorption mounting, it offers quiet operation without high-frequency interference noise and includes hot-plug protection for added reliability. Compliant with IEC 62386-101, IEC 62386-102, IEC 62386-207 Ed. 2, and IEC 62386-209, it is compatible with typical DALI mini track systems on the market, particularly A.A.G. Stucchi micro track systems.

Key Features

• Ultra-slim design DALI DT8 LED controller
• Special design for magnet track light and linear lighting
• Magnet absorption installation application, no high frequency interference sound
• DC48V input, max. 20W, max. Tc 120°C
• 2-channel 100-500mA constant current output, dips to select multi operation current
• Deep and smooth dimming to 0.1%, flicker free
• In compliance with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2, IEC 62386-209
• Built-in DALI-2 interface, DALI DT8 device
• Match typical DALI mini track systems in the market, especially with A.A.G. Stucchi micro tracks.
• Support Hot-plug protection
• Waterproof grade:IP20
• 5 years warranty
