• DALI-2 control device with standalone mode and DALI-2 instance mode
• 4 channels push switch input or dry contact motion sensor input
• Four DALI-2 push button instances are available for instance mode
• In compliance with IEC62386-101, IEC62386-103, IEC62386-301
• Functionality of standalone mode can be easily configurable through NFC
• Functionality of DALI-2 instance mode can be configurable through DALI application controller
• Multimaster capable, multiple modules can be installed on the DALI- line
• ControlledDALI device type for standalone mode can be freely configured through NFC App
• Supported device types for master mode: DT6, Tc, XY coordinates, RGBWAF
• Controlled object of each push switch for master mode can be freely configured through NFC App
• Standalone mode supports broadcast, single address, and group control
• For standalone mode, each push switch supports three different operations: short press, long press, double click
• For standalone mode, DALI command triggered by a push switch operation can be freely configured through NFC App
• DALI bus powered, no extra power supply required
• Easy installation: the device can be installed in a flush-mounted installation box
Download Center
To know further details of this product, please download the following user manual.
SR-DA2833PN-DA2-Instruction.pdf
