Product Description
With the maximum output power of 200W, this 4-in-1 200W DALI DT8 LED Driver is in compliance with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2, IEC 62386-209:2011. Featured with built-in DALI-2 interface and 4-channel 12VDC/24VDC constant voltage output, this device has a full isolated metal casing. Its PF is greater than 0.98 and its efficiency is greater than 93%. For this LED driver, 4 universal device types: primary N, Tc, XY coordinate and RGBW, can be set by the buttons. Besides, only 1 address is required to control 4 outputs separately under primary N mode. This driver is suitable for indoor LED lighting applications with 5-year warranty.
Key Features
• 4 in 1 DALI DT8 LED driver, max. output power 200W total
• In compliance with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2, IEC 62386-209:2011
• Built-in DALI-2 interface, DALI DT8 device
• 4 channels 12/24VDC constant voltage output
• Class 1 power supply, full isolated metal casing
• Power factor > 0.98, efficiency > 93%
• 4 universal device types in 1: primary N, Tc, XY coordinate, RGBW, can be set by the buttons
• DALI DT8 device to control RGBW outputs or tunable white outputs via a single DALI address
• Only 1 address required to control 4 outputs separately under primary N mode
• Control of four PWM outputs via DALI device type 8
• Color control as defined in the DALI specification device type 8
• Color type primary N, Tc, XY coordinate, RGBW can be set by manual set buttons
• Supports DT8 device commands, compatible with DALI masters that support DT8 commands
• Configuration via DALI master USB interface
• Numeric digital display for setting DALI address manually
• Compatible with universal AC push switch
• Compliant with Safety Extra Low Voltage standard
• Over load, over temperature protection
• IP20 rating, suitable for indoor LED lighting applications
• 5 years warranty
