200W 4 Channels 24VDC DALI DT6 LED Constant Voltage Driver SRPC-2305-24-200CVF

This 1-channel 48VDC constant voltage output DALI LED Driver is in compliance with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2. With built-in DALI-2/Push interface and class Ⅱ power supply, this DALI DT6 device has full isolated plastic case. Besides, with built-in active PFC function, its PF > 0.9 and its efficiency > 86%. This driver’s dimming method is PWM digital dimming, with standard DALI logarithmic dimming curve. Moreover, it is compliant with Safety Extra Low Voltage standard, coupled with over load, over temperature protection. Its protection grade is IP20, which is suitable for indoor LED lighting applications, with 5-year warranty.

Key Features

Dimmable LED driver, max. output power 200W total
In compliance with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2.
Built-in DALI-2/Push interface, DALI DT6 device
1 channel DC 24V constant voltage output
High power factor and efficiency
Built-in DALI interface, DALI DT6 device, each device is controlled via a single DALI address
PWM dimming,smooth and deep dimming to 0.1%
Compatible with universal DALI masters that support DT6 commands
Error report function
IP20 rating, suitable for indoor LED lighting applications
5 years warranty

Specifications

Part No.	Input Voltage	Frequency Range	Rated Power	Max. Output Current	Size (LxWxH)
SRP-2305-24-200LCV	220-240V AC	50/60Hz	Max. 150W	Max. 1.25A	270x79x39mm

Product Dimension

Product Dimension

Wiring Diagram

Wiring Diagram

Coming soon

Download Center

To know further details of this product, please download the following user manual.

SRPC-2305-24-200CVF User Manual.pdf
