The SR-ZG2835KAC-NK4-SW 4-Key Zigbee Push Button Smart Switch is an advanced ZigBee 3.0-based AC switch designed for versatile home automation. It supports a wide input voltage range of 100-240VAC and is compatible with resistive, capacitive, and inductive loads. With 2 channels and a maximum load of 5.1A per channel, it allows for precise control of connected lighting. The switch offers real-time energy monitoring, Touchlink commissioning, and can be controlled via ZigBee gateways, remotes, or local push buttons. It also supports self-forming ZigBee networks, direct pairing with ZigBee remotes, and binding with up to 20 ZigBee Green Power remotes. Compatible with standard EU frames and wall boxes, it operates at 2.4GHz frequency and has an IP20 waterproof rating, ensuring durability and ease of installation.
Features
•ZigBee push button AC switch based on latest ZigBee 3.0 protocol
• 100-240VAC wide input and output voltage •Supports resistive loads, capacitive loads or inductive loads
• 2 channels output, max. load 5.1A/CH
• Enables to control ON/OFF of connected light source
• Supports energy metering, real time energy consumption can be monitored
• ZigBee device that supports Touchlink commissioning
• Can be controlled by zigbee gateway, zigbee remote and local push buttons
• Can directly pair to a compatible ZigBee remote via Touchlink without coordinator
• Supports self-forming zigbee network without coordinator and add other devices to the network
• Supports find and bind mode to bind a ZigBee remote
• Supports zigbee green power and can bind max. 20 zigbee green power remotes
• Compatible with universal ZigBee gateway products
• Standard size, can be compatible with existing EU standard frames, and installed into standard size wall box
• Radio Frequency : 2.4GHz
Download Center
To know further details of this product, please download the following user manual.
SR-ZG2835KAC-NK4-SW
