SR-2307P Universal Series DALI Dimmer is a four-channel DALI-2 DT6 dimmer compliant with IEC 62386 standards. It is compatible with all major DALI systems, supports manual and automatic address setting with digital indication, and allows one to four address configuration. When used with a power repeater, output power can be expanded. Status feedback is supported.
Key Features
• In compliance with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2.
• Built-in DALI-2 interface, DALI DT6 device
• Match all DALI systems in the market
• Manual /automatically DALI address setting
• DALI address digital indicate
• Four channels, can set addresses from one to four.
• To work with power repeater to expand output power unlimitedly.
• Status feedback function
• Waterproof grade: IP20
Download Center
To know further details of this product, please download the following user manual.
SR-2307P User Manual
