This DALI-2 DT8 constant voltage LED controller is fully compliant with IEC 62386 standards and designed for advanced color and tunable white lighting applications. Featuring a built-in DALI-2 interface, it supports multi-address DT8 control and flexible 6-in-1 operation modes, including Tc, RGBWAF, XY, and DT6. With four PWM constant-voltage outputs, it enables precise color and color-temperature control via DALI or push-dim operation. Manual address setting with display, DIN-rail installation, and broad DALI master compatibility make it ideal for professional lighting systems.
Key Features
• In compliance with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2, IEC 62386-209:2011
• Built-in DALI-2 interface, DALI DT8 device
• Multi-addresses enabled DT8 control gear
• Multi-functional, 6 in 1: Tc, RGBWAF, XY, 2*Tc, XY+W (DT6), DT6
• DALI address manually assignable through manual set buttons and showed on the display
• Can be set as different device types: single-address types or multi-addresses types
• Single-address device types: Tc, RGBWAF, XY, DT6
• Multi-addresses device types: 2*Tc, XY+W (DT6)
• 4 Channels constant voltage output
• Control of four PWM outputs via DALI device type 8
• Color control as defined in the DALI specification device type 8
• Supports DT8 device commands, compatible with universal DALI masters that support DT8 commands
• Configuration via DALI master USB interface
• Color temperature and RGB color control through push dim mode even if without DALI
• DIN rail installation
• Waterproof grade: IP20
