Zigbee Door Window Sensor SR-ZG9011A-DS

The Zigbee Door Window sensor is a wireless, battery powered contact sensor, compatible with the Zigbee 3.0 standard. The device can be operated intelligently via working with a Zigbee gateway to communicate with other devices. It is a Zigbee low-energy wireless door/window sensor that makes you know the opening/closing status of door and window by separating the magnet from the transmitter. Connect it with the gateway which supports automation function and you can create a smart scene to trigger other devices.

Physical Installation
1.Peel off the protective layer from the sticker on the sensor.
2.Stick the sensor onto the door/window frame.
3.Peel off the protective layer from the sticker on the magnet.
4.Stick the magnet onto the moving part of the door/window, no further than 10mm from the sensor.
