The Casambi push button coupler features 4 dry contact inputs for connecting up to 4 standard push buttons, enabling flexible wireless control via a Bluetooth mesh network with a typical indoor range of up to 50 meters. Button functions can be freely configured in the Casambi app to control individual luminaires, groups, scenes, or the entire network. Housed in an IP20-rated enclosure, the device is reliable and backed by a 5-year warranty.
Key Features
• Casambi push button coupler
• 4 dry contacts, can connect to 4 push buttons
• Mesh network, which has a much longer control distance, transmits received signals to neighboring devices
• The range for wireless communication is about 50 meters in typical indoor environment, actual range is dependent on field installation
• Button function can be freely configured by Casambi app to control a luminaire, a group, an element, a scene, whole network, etc
• Waterproof grade: IP20
• 5 years warranty
Download Center
To know further details of this product, please download the following user manual.
SR-CS2833PAC User Manual
