SRP-2106-75CCF is an ENEC approved DMX 75w dimmable constant current LED driver with 4 channels 250mA-1500mA output that can be adjustable by DIP switches and 200-240VAC input. Power factor of the driver can be over 0.9 and efficiency is higher than 87%. It enables smooth and deep dimming to 0.1% without flickering and buzzing noise. DMX channel quantity can be set as 1/2/3/4 via buttons, which enables the driver to control single color, tunable white, RGB/RGBW LED lighting. DMX addresses can be manually assigned via buttons and showed on digital display. Complying with DMX512(2008), DMX512-A, this DMX driver is compatible with universal DMX master controllers. ENEC certification ensures high safety performance of the driver to be used worldwide.
Key Features
- Dimmable constant current LED Driver, Max. output power 75W
- ENEC certification
- 200-240VAC input
- Class Ⅱ power supply, full isolated plastic case
- Output current adjustable from 250mA to 1500mA by DIP switch on the driver
- Current accuracy < ±5%
- Rubycon capacitors
- Built-in active PFC function
- High power factor and efficiency, PF > 0.9, Efficiency > 87%
- DMX interface, DMX512(2008), DMX512-A, this DMX driver is compatible with universal DMX master controllers
- 4 DMX addresses can be manually assigned via buttons and showed on digital display
- To control constant current single color, tunable white, RGB/RGBW LED lighting
- Smooth and deep dimming to 0.1% without flickering, no buzzing noise
- IP20 rating, suitable for indoor LED lighting applications
