This ZigBee 3.0 dimmable LED driver delivers up to 10W output with 100–500mA current selectable via NFC, supporting ultra-low 0.1mA. It features high efficiency, smooth CCR/amplitude dimming, and ON/OFF control. As a ZigBee end device, it supports Touchlink commissioning, direct remote pairing, and universal ZigBee gateways. It also supports ZigBee Green Power with up to 20 switch bindings. Designed with a Class II isolated plastic case, it ensures safety, reliability, and excellent performance for indoor LED lighting.
Key Features
• Dimmable LED driver, ZigBee device based on ZigBee 3.0 protocol
• Dimmable LED driver. Max. output power 10W
• 100-500mA current selectable via NFC program tool. Min.current gear lower to 0.1mA
• Configuration via NFC program tool
• Class Ⅱ power supply, full isolated plastic case
• High power factor and efficiency
• ON/OFF, Dimming and Tunable White control
• Amplitude/CCR dimming, smooth and deep dimming
• ZigBee end device that supports Touchlink commissioning
• Can directly pair to a compatible ZigBee remote via Touchlink
• Supports zigbee green power and can bind max. 20 zigbee green power switches
• Compatible with universal ZigBee gateway products
• Waterproof grade: IP20, suitable for indoor LED lighting applications
• 5 years warranty
