The Matter + Zigbee dual-tech smart dimmer is a versatile, certified device that operates over Thread, offering seamless control of lighting. It features a wide input voltage range of 100-240VAC and supports both neutral and no-neutral wiring, adapting to various installation setups. The dimmer supports resistive, capacitive, and inductive loads, with a single-channel output of up to 500W. It provides adjustable minimum and startup brightness settings, allowing for personalized lighting control.
The device includes energy metering for real-time monitoring of power consumption and supports multiple control options, including app control through Matter (Apple Home, Amazon Alexa, Google Home), voice control (via Siri, Google Assistant, Alexa), and physical control using Touchlink remote or a green power kinetic switch. It is compatible with both leading-edge and trailing-edge configurations, preset at the factory. The dimmer also features a soft start function, smart light source detection, and is compatible with universal AC push switches. It fits standard EU frames and wall boxes, ensuring easy installation. The dimmer operates at a 2.4GHz frequency and has an IP20 waterproof rating.
Features:
• Matter + Zigbee dual tech, Matter certified device over thread
• 100-240VAC wide input and output voltage, can work under no neutral wiring and with neutral wiring, self-adaptive
• Supports resistive loads, capacitive loads or inductive loads
• Enables to set minimum brightness and startup brightness
• 1 channel output, up to 500W
• Both leading edge version and trailing edge versions are available for choosing, preset by factory setting
• Enables to control ON/OFF and light intensity of connected light source
• Supports energy metering, real time energy consumption can be monitored
• App control + touchlink remote control + green power kinetic switch control
• App control through Matter (e.g. Apple Home, Amazon Alexa, Google Home)
• Can be voice controlled through Apple Siri, Google Assistant, Amazon Alexa
• Eliminates the shortcoming of Matter having few remote and wall switch devices
• With push switch input, can be controlled by universal AC push switches
• Standard size, can be compatible with existing EU standard frames, and installed into standard size wall box
• Radio Frequency : 2.4GHz
• Waterproof grade: IP20
Main Features:
• Can operate under two-wire connection with no neutral lead or three-wire connection with neutral lead
• Advanced microprocessor control
• Implemented algorithm of smart light source detection
• Active power and energy metering functionality
• Soft start function
• Innovative minimum dimming level and startup brightness setting functions
• The Bypass is an extension unit
