150W 24V Constant Voltage 0/1-10V LED Driver SRP-2007-24-150LCV

150W 24V Constant Voltage 0/1-10V LED Driver SRP-2007-24-150LCV
150W 24V Constant Voltage 0/1-10V LED Driver SRP-2007-24-150LCV
150W 24V Constant Voltage 0/1-10V LED Driver SRP-2007-24-150LCV
Move your mouse over image or click to enlarge
SRP-2007-24-150LCV SRP-2007-24-150LCV SRP-2007-24-150LCV
Features

The SRP-2007-24-150LCV is an UL & ENEC approved 100w 0/1-10V LED dimmable driver with 220-240VAC input and 1 channel constant voltage output. The output voltage can be available in 24VDC by factory setting. Power factor of the driver can be over 0.9 and efficiency is higher than 87%. It enables smooth and deep dimming to 0.1% without flickering and buzzing noise. The LED driver can be compatible with kinds of dimming signal including 0-10V, 1-10V, potentiometer and push switch to dim and switch single color LED lighting. 1 channel 0/1-10V signal input is available for controlling of 4 channels PWM output synchronously. The 0/1-10V CV LED driver is designed with over current protection, over heat protection and short circuit protection.

Key Features

  • Dimmable LED driver
  • Max. output power 150W
  • 1 channel DC 24V constant voltage output
  • Class power supply, full isolated plastic case
  • High power factor and efficiency
  • To switch and dim single color LED lighting
  • Built-in 0/1-10V interface, 1 channel 0/1-10V signal input
  • Compatible with universal 0/1-10V signal
  • PWM dimming, smooth and deep dimming to 0.1%
  • IP20 rating, suitable for indoor LED lighting applications
  • 5 years warranty
Specifications Video User Manual Related Products
