The SR-2102HT(WP) is a waterproof 3 channel AC high voltage DMX512 controller designed with IP67 rating to control high volt RGB LED strip lights for indoor and outdoor large projects that have strict waterproof requirements. The LED strip DMX512 controller comes with 100-240VAC wide input and 100-240VDC output, which can be perfect to control high voltage LED strip and total output can be up to 1,000W. Sunricher patented high volt control technology ensures smooth dimming and RGB color tone adjustment without any flickering. Both master mode and slave mode are available for this DMX512 controller and easy to switch between the two modes. While under slave mode, the LED strip controller works as a decoder which can be compatible with a variety of RGB DMX512 master controllers. While under master mode, the DMX512 controller works as a master controller that controls via buttons and numeric digital display. IP67 waterproof rating enables the high voltage LED strip controller to be used in outdoor and damp environment.
- Waterproof High Voltage RGB DMX512 LED Strip Controller with IP67 Rating
- Master Mode and Slave Mode Switchable
- 100-240VAC Wide Input and 100-240VDC Output
- 3 Channels, Total 5A Output
- Up to 1000W Output
- Patented High Voltage Control Technology, More Stable and Reliable Than Competitors’
- Perfect to Control High Voltage LED Strip
- Smooth and Accurate Brightness and RGB Color Tone Adjustment without Flickering
- Compatible with A Variety of RGB DMX512 Masters under Slave mode
- Manual control via buttons and digital display under Master mode
|Part No.||Input Voltage||Output Current||Output Voltage||Output Power||Dimension (mm)|
To know further details of this product, please download the following user manual.
SR-2102HT(WP) User Manual
