Product Description
With standard DMX512 compliant control interface, the RDM function enables this Waterproof DMX512 Decoder realize intercommunication between DMX master and decoder. For example, DMX decoder’s address can be assigned by DMX master console. With digital display, this device can show data directly, and set and show DMX address easily. Besides, it has total 4 PWM output channels and common anode. DMX address can be set manually, DMX channel quantity can be set from 1CH~4CH, output PWM frequency can be set from 500HZ to 35KHZ, and output dimming curve gamma value can be set from 0.1 to 9.9. This decoder can work with power repeater to expand output power unlimitedly. And the waterproof grade is IP67.
Key Features
• Standard DMX512 compliant control interface
• RDM function enabled to realize intercommunication between DMX master and decoder.
• For example, DMX decoder’s address can be assigned by DMX master console
• With digital display to show data directly, easily to set and show DMX address.
• Total 4 PWM output channels, common anode
• DMX address manually settable
• DMX channel quantity from 1CH to 4CH settable
• Output PWM frequency from 500HZ to 35K HZ settable.
• Output dimming curve gamma value from 0.1 to 9.9 settable
• To work with power repeater to expand output power unlimitedly.
• Waterproof grade:IP67
