Product Description
This RDM Enabled 4 Channels DMX Phase Dimmer is with safe and reliable full isolation design. With trailing edge dimming, this DMX phase dimmer supports resistive loads and capacitive loads. It has standard DMX512 compliant control interface. RDM function enables it to realize intercommunication between DMX master and decoder. For example, DMX decoder’s address can be assigned by DMX master console. By virtue of digital display to show data directly, this device can easily set and show DMX address. DMX channel quantity is from 1CH~4CH settable, and output dimming curve gamma value ranges from 0.1 ~ 9.9 settable, with 4 channels AC100-240V output. It can dim single color dimmable LED lamps, dimmable LED driver, traditional incandescent and halogen lights.
Key Features
• Safe and reliable full isolation design
• DMX phase dimmer, trailing edge dimming
• Supports resistive loads and capacitive loads
• Standard DMX512 compliant control interface
• RDM function enabled to realize intercommunication between DMX master and decoder.
• For example, DMX decoder’s address can be assigned by DMX master console
• With digital display to show data directly, easily to set and show DMX address
• DMX channel quantity from 1CH~4CH settable
• Output dimming curve gamma value from 0.1 ~ 9.9 settable
• 4 channels AC100-240V output
• To dim single color dimmable LED lamps, dimmable LED driver, traditional incandescent and halogen lights
• Din rail installation, easy and fast
• Waterproof grade: IP20
