Constant Voltage DALI Dimmer SR-2303B

The DALI Dimmer SR-2303B is a constant voltage LED dimming controller with 4 channel 5A per channel output, which complies with standard DALI protocol with 4 DALI addresses to control 4 channel separately. The DALI address can be manually assigned and shown on the numeric digital display or automatically assigned by master controllers. 4 DALI addresses are available for 4 channels to work separately. 0%-100% smooth dimming can be achieved by the DALI dimmer via logarithmic dimming, which is perfect for human's vision.

Key Features

• DALI certified
• TUV CE certified
• 4 DALI addresses, 4 channels work separately.
• Constant voltage DALI LED dimmer with 4 channel, 5A per channel output available in 12VDC, 24VDC and 36VDC output.
• In accordance with DALI standard protocol IEC 62386-102, IEC 62386-207 and in compliance with DALI products from other international incorporation.
• DALI address can be manually assigned and shown in numeric digital display or automatically assigned by master controller.
• 4 DALI addresses, 4 channels work separately.
• 0%-100% dimming range via logarithmic characteristic, perfect for human's vision.
• To work with LED lights to establish DALI lighting system.
• To work with power repeater to expand output unlimitedly.
