SRP-2106-24-50CV is a DMX 50w dimmable constant voltage LED driver with 1 channel 24VDC output, 12V output version is also available. It is designed with 200-240VAC input. Power factor of the driver can be over 0.9 and efficiency is higher than 85%. It enables smooth and deep dimming to 0.1% without flickering and buzzing noise. 1 DMX address can be manually assigned via buttons and showed on digital display. Complying with DMX512(2008), DMX512-A, this DMX driver is compatible with universal DMX512 master controllers.
Key Features
- Dimmable Constant Voltage LED Driver, Max. output power 50W
- 1 channel 12VDC or 24VDC constant voltage output
- Class Ⅱ power supply, full isolated plastic case
- Rubycon capacitors
- Built-in active PFC function
- High power factor and efficiency, PF > 0.9, Efficiency > 85%
- Complying with DMX512(2008), DMX512-A, this DMX driver is compatible with universal DMX512 master controllers
- 1 DMX address can be manually assigned via buttons and showed on digital display
- To control constant voltage single color LED lighting
- Smooth and deep dimming to 0.1% without flickering, no buzzing noise
- IP20 rating, suitable for indoor LED lighting applications
