5 Channel Constant Current DMX512 Decoder SR-2105FA7

The SR-2105FA7 is a 5 channel constant current DMX512 decoder with 0.7A per channel output, which can be switched between DMX decoder mode and stand-alone mode by button. Once under stand-alone mode, the DMX master can adjust brightness of each channel and enter the fading operation mode. 3 channel, 4 channel or 5 channel output can be selectable. DMX address can be set freely and shown on the numeric digital display.

Key Features

• 5 channel constant current DMX512 decoder with 0.7A per channel output
• DMX512 compliant control interface, DMX address can be set freely and shown on the digital numeric display
• Stand-alone mode and DMX512 decoder mode can be freely switched by buttons
• Once under stand-alone mode, the DMX master can adjust brightness of each channel and enter the fading operation mode
• 3 channel, 4 channel or 5 channel output selectable
• To work with power repeater to expand output unlimitedly
