SRP-2305-12-100CVF is an UL and ENEC approved DALI 100w dimmable LED driver with 4 channels 12VDC constant voltage output and 100-277VAC universal input. Power factor of the driver can be over 0.9 and efficiency is higher than 90%. It enables smooth and deep dimming to 0.1% without flickering and buzzing noise. DALI address quantity can be set as 1/2/3/4 which enables the driver to control single color, tunable white, RGB/RGBW LED lighting. DALI addresses can be manually assigned via buttons and showed on digital display or automatically assigned by DALI masters. Complying with IEC62386-101, 102, 207, this DALI driver is compatible with universal DALI masters. UL and ENEC certification ensures high safety performance of the driver to be used worldwide.
Key Features
- Dimmable 12V LED Driver, Max. output power 100W
- UL and ENEC certification
- 100-277VAC universal input
- 4 channels 12VDC constant voltage output
- Class Ⅱ power supply, full isolated plastic case
- Rubycon capacitors
- Built-in two stage active PFC function
- High power factor and efficiency, PF > 0.9, Efficiency > 90%
- Complying with IEC62386-101, 102, 207, this DALI driver is compatible with universal DALI masters
- DALI addresses can be manually assigned via buttons and showed on digital display or automatically assigned by DALI masters
- Fade time, system failure level, power on level configurable
- To control constant voltage single color, tunable white, RGB/RGBW LED lighting
- Smooth and deep dimming to 0.1% without flickering, no buzzing noise
- Error report function
- IP20 rating, suitable for indoor LED lighting applications
