SRP-2106-75W-CCT is an UL and ENEC approved DMX 75w dimmable constant current LED driver with 2 channels 250mA-1500mA output that can be adjustable by DIP switches and 100-277VAC wide input. Power factor of the driver can be over 0.9 and efficiency is higher than 87%. It enables smooth and deep dimming to 0.1% without flickering and buzzing noise. DMX channel quantity can be set as 1/2 via buttons, which enables the driver to control single color, tunable white LED lighting. DMX addresses can be manually assigned via buttons and showed on digital display. Complying with DMX512(2008), DMX512-A, this DMX driver is compatible with universal DMX master controllers. UL and ENEC certification ensures high safety performance of the driver to be used worldwide.
Key Features
- Dimmable constant current LED Driver, Max. output power 75W
- UL and ENEC certification
- Universal input 100-277VAC
- Class Ⅱ power supply, full isolated plastic case
- Output current adjustable from 250mA to 1500mA by DIP switch on the driver
- Current accuracy < ±5%
- Standby power consumption < 0.5W
- Rubycon capacitors
- Built-in active PFC function
- High power factor and efficiency, PF > 0.9, Efficiency > 87%
- DMX interface, DMX512(2008), DMX512-A, this DMX driver is compatible with universal DMX master controllers
- 2 DMX addresses can be manually assigned via buttons and showed on digital display
- To control constant current single color, tunable white LED lighting
- Smooth and deep dimming to 0.1% without flickering, no buzzing noise
- IP20 rating, suitable for indoor LED lighting applications
