SRP-2305-24-50CVT is a DALI 50w dimmable constant voltage LED driver with 2 channels 24VDC output, 12VDC version also available, which enables it to be suitable for CCT LED lights with different voltage. It is designed with 200-240VAC input. Power factor of the driver can be over 0.9 and efficiency is higher than 85%. It enables smooth and deep dimming to 0.1% without flickering and buzzing noise. 2 DALI addresses can be manually assigned via buttons and showed on digital display or automatically assigned by DALI masters. Complying with IEC62386-101, 102, 207, this DALI driver is compatible with universal DALI masters.
Key Features
- Dimmable Constant Voltage LED Driver, Max. output power 50W
- 2 channels 12VDC or 24VDC constant voltage output
- Class Ⅱ power supply, full isolated plastic case
- Rubycon capacitors
- Built-in active PFC function
- High power factor and efficiency, PF > 0.9, Efficiency > 85%
- Complying with IEC62386-101, 102, 207, this DALI driver is compatible with universal DALI masters
- DT6/DT8 (color type Tc) optional
- Fade time, system failure level, power on level configurable
- 2 DALI addresses can be manually assigned via buttons and showed on digital display or automatically assigned by DALI masters
- To control constant voltage CCT LED lighting
- Smooth and deep dimming to 0.1% without flickering, no buzzing noise
- Error report function
- IP20 rating, suitable for indoor LED lighting applications
